Main Features

1. Uniform and dense zinc coating delivers excellent corrosion resistance and can resist humid, rainy and atmospheric corrosion in outdoor environment for a long time;

2. The plate is flat and smooth with high dimensional accuracy and good performance for stamping, bending and forming;

3. Spangled and zero-spangled surface are optional for direct application or subsequent spraying and coating treatment;

4. Raw coils can be flexibly slit and cut to length, supporting customization of various non-standard small sheets such as 620×465.

Technical Parameters

1. Substrate: Low-carbon cold-rolled steel, grades including SPCC, DC01;

2. Thickness: 0.15mm–3.0mm; Width: 600mm–1500mm; Thickness tolerance ±0.03~±0.10mm, width tolerance ±2mm;

3. Zinc coating mass: Z40~Z275g/㎡; Surface: Spangled / Zero-spangled; Zinc coating passes bending test without peeling;

4. Standard: GB/T 2518; Supply form: steel coil, cut-to-length plate, non-standard small sheets (e.g. 620×465);

5. Packaging: Moisture-proof and anti-rust wrapping, bare coil or wooden pallet packaging, suitable for sea and land transportation & storage.

Application Fields
Steel structure purlins, wall & roof components of workshops; ventilation & air-conditioning ducts, fire-vent components; high-low voltage distribution boxes, outdoor power cabinet housings; automotive chassis guards, interior stamping parts; storage rack uprights and decks; photovoltaic brackets and inverter cabinets; mechanical equipment housings and shields; municipal guardrails, street light parts, bus-stop metal components; hardware stamping, sheet-metal bending, cabinet manufacturing, agricultural greenhouse frames.


Company and service advantages:

1.The company workshop 40,000 square meters, has introduced the first-class multi-station machining center, CNC lathes, CNC milling machines and other high-precision processing equipment. Such as the value of 4.5 million yuan 3mx8m gantry machining center, and the value of 300 million yuan 2.5 mx12m gantry milling machine.

2.The company has a professional The Adjuster team, 24 hours to provide uninterrupted after-sales service.
(1) Installation and debugging
Equipment arrived at the customer workshop, according to the flat layout of our equipment. We will arrange experienced technicians to install, debug and test-produce the equipment, and make the equipment reach the rated production capacity of the production line.
(2) Training
Our company provides technical training for our customers. The training includes the structure and maintenance of the equipment, the control and operation of the equipment, experienced technicians will guide and establish the training program. After training, the buyer's technical personnel can master the operation and maintenance of the equipment, can adjust the process and deal with different failures.

3.After-sales quality problems within 2 hours to answer, if the telephone video guidance can not be solved, domestic 24 hours to send engineers to the site to solve the problem.

4. Factory direct sales price concessions, 40,000 square meters factory, 20 years of Export Enterprises, CE certification, patents more than 100 items.
